The entire machine adopts stainless steel shell, it is reliable and durable.
Opted imported Philip specific printer lamp, Philip rectifier(frequency transformingtype is good for registering).
Characteristics
The entire machine adopts stainless steel shell, it is reliable and durable.
Opted imported Philip specific printer lamp, Philip rectifier(frequency transformingtype is good for registering).
Imported slow reflective violet suction membrane(Japan Toyo)
Computer controller enables it to be easily operated.
Adopted American digital intergrated thermo sensor.
Adopted American thermo sensor.
Japanese Panasonic or oriental printing plate washer, Japanese ORIX constant dry.
Integrating exposure, washing and drying functions, it is the ideal equipment for resin plate production.
Main Technical Parameters
|
Model |
Printing area |
Measurement (W x D x H) |
Power |
|
ZX-A4 |
430mmX255mm |
710X550X1050(mm) |
2.2kw |
|
ZX-400 |
430mmX300mm |
710X600X1050(mm) |
2.3kw |
|
ZX-600 |
600mmX400mm |
860X710X1050(mm) |
2.6kw |
|
ZX-800 |
800mmX600mm |
1090X910X1150(mm) |
3.5kw |
|
ZX-900 |
900mmX600mm |
1190X910X1150(mm) |
3.7kw |
|
1000mmX600mm |
1290X910X1150(mm) |
3.9kw |
Accept special orders.
